TIAARA
TIA-CHR-73681N TIA-CHR-73683N
In-wall thermostatic shower valve with 2-way diverter In-wall thermostatic shower valve with 3-way diverter
Flow rate: 40.63 l/min* Flow rate: 55.24 l/min*
3/4"BSP Outlet Min. 60
Min. 60 105 3/4"BSP Outlet Max. 85 38 105
80 Max. 85
102
OFF II
3/4"BSP Outlet 3/4"BSP Outlet I II 3/4" BSP Outlet I OFF III
270 NRV 280 + 38° 297 NRV 3/4" BSP Cold Inlet 280 + 38°
3/4"BSP Hot Inlet 3/4"BSP Cold Inlet 3/4" BSP Hot Inlet
WALL FLANGE WALL FLANGE
PLUG PLUG
